妙用与概述/Brief Introduction：

全自己齿轮泵式膏体酱分安装系统是爱大公司融入整个市场实际需求设计的新软件。该机型主要包括SUS304装饰管齿轮泵式记量泵制定分装，且集自己上盖、自己旋盖、机械设备电器为分离式，资金实用性，占地赔偿建筑面积小，丰富应该用于药业有限公司、食物、除草剂、化工公司、妆后品等市场的透明液体外包装，包含GMP规定的要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优点和缺点/characteristic：

◆用到液压泵式检定泵继续执行灌装线，实用各方面浓稠度固体，gps精较高；泵的节构用到快接式拆装工作机购，更加方便洗涤、紫外线灯消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆轴向柱塞泵式记量泵柱塞环材料要根据企业及粘液化学物质的各种利用硅天然橡胶，四氟乙稀或另一材料，特俗施工地点利用瓷砖材料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调整设备，交流变频调压，自動化系数高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，系统自动计数器效果。Lack of bottle filling, automatic counting function◆装量调低便宜，可以次调低所有计算校准泵的充填量，也可涉及很多计算校准泵做微幅调低；工作简约，调低迅速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头可设防漏滴设备，充填时溜进瓶底包装，极慢增长，预防泡沫。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆空机可适用人群有所差异样式的小瓶，修整简易，可在短日子间内来完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆该机按GMP想要设置。The machine designed according to the requirements of GMP

能力性能指标/technic parameter：

使用小瓶要求Size of bottles	20-1000ml（按照其请求订作）20-1000 - ml (according to your need）
应用小瓶直径不低于Apply the bottle diameter	¢20-¢150mm
可用于盖子技术参数Apply the lid specifications	¢20-¢70mm
生产方式效率 production capacity	四头灌装生产线：1000-2500瓶/分钟 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/h Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/小时英文 12 head filling: 4000-6000 bottles per hour
装量误差值The load error	±1%
旋盖符合标准率Screw cover percent of pass	≥99%
供电power supply	380V，50HZ
马力power	3.0KW
氧气减压阀gas sources	0.4-0.75MPA
强度抑制speed control	变频器可控硅调压variable speed
