的主要用途是什么与概况/Brief Introduction:
远程服务器是成为服食液磨砂夹丝玻璃容器的新物料,可以彻底处理好了以前服食液磨砂夹丝玻璃容器的异常功效。此类灌封机用到的塑瓶,这样不仅不要求洗瓶机、风干机,更不要求消毒剂,可随时灌封。该机型白动化理瓶、进瓶、装罐线,装罐线量不稳固性,无漏滴,无瓶不装罐线。上盖、粘口率可以达到100%。此机水平最新,面积小、运转不稳固性、躁音低,工作维修费、洗方便快捷等优势,可以符合标准规定GMP标准规定。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注:本机型有中速和飞速哪几种收获量供您选定。Note: this model has two kinds of low speed and high-speed production for your choice.特征 Characteristic
◆超声波焊接机采用于各种各样易折瓶口服药液压力容器检验灌装设备和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆所有的电器设备器件均按照前十强国际品牌。All electrical components adopt famous brand◆机器基本操作直观性 省事,无瓶不灌装生产线,计量校准*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料制品瓶灌封机的首要机构与原则Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型服用液易折材料瓶灌封机常见理瓶器、理盖器、主转动机系统、同步操作带宽度送小瓶置、空罐检漏部件、包装单位、去掉部件、热溶封单位、油路分配器机械装备指头夹瓶单位、步进驱动器马达宽度上瓶单位与出瓶单位等包含。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机器设备施用的内服液易折朔胶瓶、盖是一种定净化区生产方式的,应用泡脚药材经营许可资料证,所以说瓶身与底盖经交换和"去承包"后可直接的渗入灌封间。完成理盖器、理瓶器的自然定向生培养整里,剔出逆向底盖及瓶身底口朝下的瓶,使定向生培养后的包材喂料有标准地渗入运输导轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆方向后口服方式液易折塑料管瓶在输送带行列第二排Directional oral liquid after folding plastic bottles in conveying rail out easily工艺因素technical parameters:
型号model | NLGFY-40 | NLGFY-80 |
装量标准The load range | 5-100ML | |
生产能力production capacity | 20-40瓶/分 | 50-80瓶/分 |
密封率Hot sealing intensity | 》99% | |
装量偏差The load error | 《1.5% | |
已经破损率damage rate | 《1.0% | |
耗油率power | 2KW | 3KW |
交流电源Power Supply | 380V 50Hz/220V 50Hz | |
外形尺寸boundary dimension | 2700*1100*1900mm | 3000*1480*1900mm |
含水量 Weight | 700Kg | 800Kg |
